DuraMac EQ6602ZT6D Four Wheel Drive Bus
The Dongfeng EQ6602ZT6D is a National VI-certified passenger vehicle engineered for versatile transit needs. Manufactured with a focus on durability, it is powered by the Dongfeng Cummins D4.5NS6B220 engine, ensuring compliance with stringent emission regulations while delivering dependable performance for urban and intercity use.
Boasting a 5990mm overall length and 3700mm wheelbase, the model optimizes space efficiency to seat 10–19 passengers. Its 1900mm interior height enhances passenger comfort, complemented by a maximum speed of 100km/h, making it suitable for short to medium-distance transportation scenarios.
With a 11950kg maximum total mass and 360mm ground clearance, the EQ6602ZT6D excels in adaptability. Paired with a 4.5L displacement engine generating 162kW power, it combines robust load capacity with stable dynamics, ideal for diverse fleet operations.
Advantages of EQ6602ZT6D Four-wheel Drive Bus
-
Robust and Reliable Powertrain Output:The engine delivers a maximum power of 162 kW at 2500 rpm and a peak torque of 820 N·m from 1300–1500 rpm, ensuring strong low-speed torque and smooth power delivery for stable performance under various load conditions.
-
Optimized Passenger Capacity and Space Utilization:With a passenger capacity of 10–19 seats and a wheelbase of 3700 mm, the vehicle balances compact maneuverability (total length 5990 mm) with a spacious 1900 mm interior height, making it ideal for urban and medium-distance transit.
-
Enhanced Stability and Adaptability:Boasting a maximum total mass of 11950 kg, a minimum ground clearance of 360 mm, and a track width of 2000/2000 mm, the model provides excellent stability and terrain adaptability, ensuring reliable operation on diverse road surfaces.
Technical Specifications
| Total Length (mm): | 5990 |
| Total Width (mm): | 2530 |
| Total Height (mm): | 3225(flat top)/3290(Ordinary skylight )/3465(air conditioner) |
| Interior Height (mm) | 1900 |
| Wheelbase front/back(mm): | 2000/2000 |
| Front Suspension / Rear Suspension (mm): | 910/1380 |
| Approach/Departure Angle (°): | 40/33 |
| Step Height (mm): | 360 |
| Rated Maximum Gross Vehicle Weight (kg) | 11950 |
| Rated Number of Passengers (Persons) | 10-19 |
| Top Speed (km/h) | 100 |
| Emission Standard | National VI |
Model |
Total Length(mm) |
Overall Width(mm) |
Total Height(mm) |
Maximum Speed (km/h) |
Maximum Total Mass(kg) |
| EQ6602ZT6D | 5990 | 2530 | 3225(flat top)/3290(ordinary car)/3465(air conditioner) | 100 | 11950 |
| EQ6600ZT6D | 5990 | 2280 |
2810(ordinary car)/3030(Full roof air conditioning) |
100 | 7300 |
| EQ6680ZT6D | 6800 | 2280 | 3020 (ordinary car)/ 3155 (Full roof air conditioning) |
100 | 8150 |
| EQ5070XYBT6D | 5990 | 2280 | 2810(ordinary car)/3030(Full roof air conditioning) | 100 | 7300 |
| ------END------ | |||||
Basic information of Dongfeng EQ6602ZT6D motor |
|||
| Engine Model | D4.5NS6B220 | Engine Manufacturer | Dongfeng Cummins Engine Co., Ltd |
| Location/Fuel Type | Front-mounted/Diesel | Enginetype | Inline four-cylinder, four-stroke, water-cooled, turbocharged and intercooled |
| Maximum power (kw) | 162/2500 | Maximum Torque (Nm/rpm) | 820/1300~1500 |
| Displacement (L): | 4.5L | Emission Standard: | China VI |
| ——END—— | |||
Chassis Parameters And Configuration |
||
| Item | Standard Configuration | Optional configuration |
| Chassis Model | EQ6581KZ6T, Dongfeng Special Vehicle Co., Ltd | — — |
| Transmission | F6A75, Fast Shuangte 6AT | Allison 6AT |
| Clutch | Flexible disc + torque converter | — — |
| Front Axle | Dajiang Axle, disc type | — — |
| Rear Axle | Dajiang Axle, disc type | — — |
| Suspension | Leaf spring (few leaves), 3 leaves front / 4 leaves rear | — — |
| Steering | Power steering | — — |
| Braking | Pneumatic braking, condenser, air dryer, engine exhaust brake, ABS, ESC, brake wear alarm | ADAS (Advanced Driver Assistance Systems) |
| Fuel Tank | 200L | — — |
| Tires | 365/80R20, 14PR | — — |
| Battery/Generator | 6-QW-120MF×2, 28V 150A alternator | — — |
| others | Copper radiator, engine preheating, urea heating, cruise control, front & rear differential locks, steering damper | Central tire inflation/deflation system, centralized lubrication system, electric winch, fuel line heating |
| ------END------ | ||
Main body Assembly |
||
| Item | Standard Configuration | Optional configuration |
| Body structure | Body-on-frame construction | — — |
| Interior | Cab interior, molded headliner interior, left/right pillar trims, door claddings, instrument panel | — — |
| Doors and Door Pumps | Driver & co-driver doors (electric window lift), manually outward-opening passenger door, rear enclosure outward-opening door | — — |
| Side Windows | Built-in sliding window | Fully bonded glass, no side window structure |
| Windshield | Laminated front windshield | Tempered rear windshield glass |
| Rearview System | Steel-frame symmetric manual lever-type rearview mirror, blind spot mirror, front lower vision mirror | Steel-frame symmetric electric lever-type rearview mirror |
| Air - conditioning System | — — | — — |
| Heating System | — — | — — |
| — — | — — | |
| — — | — — | |
| — — | — — | |
| Defroster | Instrument panel built-in air conditioning (borrowed) | Independent defroster |
| Audio-visual System | Multi-function steering wheel, 12.3-inch multi-function display | — — |
| Lamp | Front round lamp assembly, rear lamp assembly | — — |
| Wiper | Parallel-wiping electric wiper | — — |
| Hatch Door | — — | — — |
| Seats | — — | — — |
| Paint | Customizable colors, domestic solid-color paint | — — |
| Others | Driver’s airbag shock-absorbing seat + 2 mid-range co-driver seats, side compartment doors, front/rear/left/right bumpers, left boarding ladder, right boarding handrail, front/rear roof racks, left passenger door flip step (manual), front/rear lamp protective nets, front enclosure air grilles (upper left/lower left/middle/upper right/lower right), Beidou satellite positioning driving recorder with printing function, OBD port, heavy-duty vehicle remote emission terminal T-BOX, reflective vest, triangular wheel chock, wading depth 800-900mm, engine compartment manual-integrated fire extinguishing device, air horn | Remove side compartment doors, skylight, roof-mounted air conditioning, no rear passenger door, rear luggage box, front windshield anti-riot protective net, 360° surround view, one-key start |
| ------END------ | ||
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
